Construction Wire Mesh for Global Export
Construction wire mesh is a critical reinforcement material used in concrete structures, infrastructure, and industrial projects. Our products comply with international standards and cater to regional requirements. Below are detailed specifications in tabular format, along with key features and applications.
1. British Standard Series (BS 4483:2005)
- Material: Low-carbon steel (Grade 500A)
- Surface Treatment: Electro-galvanized / Hot-dipped galvanized (Z275)
- Applications: Slab reinforcement, partitions, lightweight concrete.
| Wire Diameter (mm) | Mesh Size (mm) | Sheet Dimensions (m) |
|---|---|---|
| 3.0 – 6.0 | 100×100 – 200×200 | 2.4×1.2, 2.4×2.4 |
2. ASTM A185 Series (USA Market)
- Material: Carbon steel (high tensile)
- Surface Treatment: PVC-coated (green/black) / Hot-dipped galvanized
- Applications: Concrete pavements, retaining walls.
| Wire Diameter (mm/in) | Mesh Size (mm/in) | Sheet Dimensions (m) |
|---|---|---|
| 3.4 / 0.135″ | 100×100 / 4×4″ | 3.0×1.5, 3.0×2.4 |
3.AS/NZS 4671:2001 Series (Australia/New Zealand)
- Material: High-tensile steel (Grade 500E)
- Surface Treatment: Hot-dipped galvanized (Z275)
- Applications: Structural slabs, fencing.
| Wire Diameter (mm) | Mesh Size (mm) | Sheet Dimensions (m) |
|---|---|---|
| 4.0 – 5.0 | 100×100 – 150×150 | 6.0×2.4, 5.4×2.4 |
4.European Norm Series (EN 10080-3)
- Material: B500B/B500C steel
- Surface Treatment: Epoxy-coated / Galvanized
- Applications: Industrial flooring, bridge construction.
| Wire Diameter (mm) | Mesh Size (mm) | Sheet Dimensions (m) |
|---|---|---|
| 5.0 – 8.0 | 150×150 – 250×250 | 2.0×1.0, 3.0×1.5 |
5.JIS G3551 Series (Japanese Market)
- Material: SS400 mild steel
- Surface Treatment: Pre-galvanized (Z12 coating)
- Applications: Earthquake-resistant structures.
| Wire Diameter (mm) | Mesh Size (mm) | Sheet Dimensions (m) |
|---|---|---|
| 3.2 – 4.5 | 50×50 – 150×150 | 1.8×0.9, 2.1×1.05 |
6.Custom Solutions
Middle East Market:
| Wire Diameter (mm) | Mesh Size (mm) | Sheet Dimensions (m) |
|---|---|---|
| 4.0 – 6.0 | 100×100 – 200×200 | 3.0×1.0, 3.0×2.0 |
African Market:
| Wire Diameter (mm) | Mesh Size (mm) | Sheet Dimensions (m) |
|---|---|---|
| 3.0 – 5.0 | 150×150 – 300×300 | 2.0×1.0, 2.4×1.2 |
Key Features:
✅ Durability: Corrosion-resistant coatings (galvanized, PVC, epoxy).
✅ Flexibility: Custom sheet sizes and mesh configurations.
✅ Certified: Compliant with ISO, ASTM, BS, EN, and regional standards.
